1 Ejector 120T High Speed Vertical Injection Molding Machine JTT-1200 HS

Name: 1 Ejector 120T High Speed Vertical Injection Molding Machine JTT1200 HS
Brand: JINTONG
Price: 21500.00 USD

Quality 1 Ejector 120T High Speed Vertical Injection Molding Machine JTT-1200 HS for sale

Brand Name : JINTONG

Model Number : JTT-1200 HS

Place of Origin : Guangdong, China

MOQ : 1PC

Price : $21500.00 --23500

Supply Ability : 600 Piece/Pieces per Month JINTONG vertical injection molding machine JTT-1200

Delivery Time : 35 days

Packaging Details : PLYWOOD CASE

Plastic Processed : LCP

Condition : New

Style : VERTICAL

Plasticizing Capacity(g/s) : 177

Mold Height(mm) : 210 - 400 mm

Ejector Number : 1

Ejector Stroke(mm) : 75 mm

Ejector Force(kN) : 33 kN

Theoretical Shot Volume(cm³) : 353 cm³

Injection Rate (g/s) : 177 g/s

Machine Type : Hydraulic

Injection Weight (g) : 321 g

Screw Speed (rpm) : 1 - 180 rpm

Screw diameter (mm) : 50 mm

Screw L/D Ratio : 22

Distance between Tie Bars : 620x280 mm

Weight (KG) : 3800 kg

Type : Other

Open Stroke(mm) : 250 mm

Power (kW) : 22.5 kW

Warranty : 1 Year

Key Selling Points : High Safety Level

Applicable Industries : Manufacturing Plant

Showroom Location : None

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Pump, PLC, Pressure vessel

After-sales Service Provided : Engineers available to service machinery overseas

opening force : 120T

platen size : 840*500mm

max daylight : 450MM

min old height : 200MM

After Warranty Service : Video technical support

Port : SHENZHEN

Contact Now

Product Description

1 Ejector JINTONG 120T high speed Vertical Injection Molding Machine JTT-1200 HS

Clamping Force: 120T

Injection Weight: 50-321G

Vertical clamping, vertical injection
Optional saving energy motor
Combined with conveyor system used on production line

1 Ejector 120T High Speed Vertical Injection Molding Machine JTT-1200 HS

Main Features

With lower mold can slid out towards operation direction, inserts, placed parts and finished products are all finished outside the clamping unit. It works safely and suits for those inserts that are hard to place.

Suitable for all kinds of insert molding.

Nitrided steel screw and barrel, directly driven by high torque motor, with multi stages injection pressure, better plasticization.

Vertical compression clamping system, closing mold with high speed lower pressure as well as multi pressure control and prolong mold using life.

Electric protection device can not happen wrong action and maintain the operators safety.

Auto life injection base, it is easy for replacement of material and mold.

Certifications

Detailed Images

Our Service

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
